Caleffi 521115 15mm MixCal Thermostatic Mixing Valve

Model: 521215

Size: 15mm compression

Body: Brass DZR Chrome plated

Performance

Medium: Water

Temperature adjustment range:  30 ^OC – 50 ^OC

Temperature control: + 2 ^OC

Max. working pressure (static)     10 bar

Max, working pressure (dynamic) 0.2 bar

Max unbalanced dynamic supply: 12:1

(hot/cold or cold/hot)

Max hot water inlet temperature: 85 ^OC

Max pressure differential: low pressure: 0.4 bar

between hot and cold supplies    high pressure: 2.0 bar
Flow rate under 1 bar:      1400 ltr/hour

pressure differential:

Minimum temperature differential

between hot inlet and mixed water

outlet to ensure fail safe function: 10 ^OC

Application

The Careflo thermostatic mixing valve has been tested and approved by the National Health Service as a class 3 and National Health Service model engineering specification – D08.  The valve being suitable for the following applications:-

Wash hand basin – high and low pressure

Showers – high and low pressure

Bidets – high and low pressure

Baths 44 ^OC fill (unassisted) – High pressure

Baths 46 ^OC fill (assisted) – High pressure

The Caleffi Careflo thermostatic valve is suitable for installation on systems where more than one outlet is required to be served, provided that the supply conditions permit.

The Careflo has been designed to provide an operating temperature range of 30 ^OC to 50 ^OC.
